zł1,696.63 tax excl.
The set with the RM502Q-AE module is designed to work with the Raspberry Pi minicomputer. It supports 5G, 4G and 3G networks and supports GNSS positioning. Waveshare RM502Q-AE 5G HAT (EU)
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The set with the RM502Q-AE module is designed to work with the Raspberry Pi minicomputer. Provides communication in 5G networks with compatibility in 4G and 3G networks and supports GNSS positioning within GPS, GLONASS, BeiDou and Galileo systems.
It communicates via the USB port and has support for Windows, Android and Linux. The base board is equipped with an M2 connector, thanks to which it enables connection with various communication modules with a M2 B Key connector. The board also has a USB port and two SIM card slots. The set is connected to the Raspberry Pi using a standard 40-pin connector. The set includes adapters, antennas and a cooling fan. Full documentation is available on the product Wiki page.
Features
- 5G NR NSA: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n48*, n66, n71, n77, n78, n79
- 5G NR SA: n1, n2, n3, n5, n7, n8, n12, n20, n25, n28, n38, n40, n41, n48*, n66, n71, n77, n78, n79
- LTE-FDD: B1, B2, B3, B4, B5, B7, B8, B12(B17), B13, B14, B18, B19, B20, B25, B26, B28, B29, B30, B32, B66, B71
- LTE-TDD: B34, B38, B39, B40, B41, B42, B43, B48
- LAA: B46
- UMTS WCDMA: B1, B2, B3, B4, B5, B6, B8, B19
- GNSS: GPS, GLONASS, BeiDou, Galileo
- Data transfer rate:
- 5G SA Sub-6: Download 4.2 Gbps; 450 Mbps upload
- 5G NSA Sub-6: Download 5 Gbps; sending 650 Mb/s
- LTE: download 2 Gb/s; upload 200 Mb/s
- UMTS: download 42 Mbps; sending 5.76Mb/s
- 2 x SIM card slot
- 4 x SMA antenna connector
- ON / OFF switch
- Reset button, LED indicator
- Power supply 5V, 3A
- Module dimensions: 56.7 x 85 mm
Kit contains
- 5G Module
- M.2 TO 4G/5G HAT
- 4 x external antenna
- 4 x IPEX adapter
- USB cable
- USB3.0 adapter
- USB2.0 adapter
- 2x20-pin terminal block
- Screw package
- USB power adapter
- SMA protective caps
