New products
New products
zł42.50 tax excl.
4-color e-Paper display with a diagonal of 2.66" and a resolution of 360x184 px. It uses communication via the SPI interface. The set includes only the display without a PCB. Waveshare 2.66inch e-Paper (G)
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
4-color (red, yellow, black and white) e-Paper display with a diagonal of 2.66" and a resolution of 360x184 pixels. Thanks to the two-level gray scale, you have control over the details and depth of the presented image. The e-Paper display is a real achievement in technology, capable of displaying content with high contrast while consuming minimal power, making it ideal for projects where energy efficiency is key.
The integrated controller enables smooth communication via the SPI interface, ensuring fast and reliable data transmission. This display is also characterized by a wide viewing angle, which makes the presented content readable from various perspectives. The module is user-friendly, working with 3.3 V systems. Additionally, the product page includes use cases for popular platforms such as Raspberry Pi, Jetson Nano, Arduino and STM32, which facilitates integration and project development.
Features
- Diagonal: 2.66"
- Resolution: 360x184 px
- Display color: red, yellow, black, white
- Gray levels: 2
- Interface: 3-wire SPI, 4-wire SPI
- Pixel size: 0.1668 x 0.1668 mm
- Full refresh time: 26 sec
- Power consumption: up to 50 mW
- Viewing angle: > 170°
- No backlight, displays the last content after power off
- Low energy consumption
- Operating voltage: 3.3V
- Display size: 60.05 x 30.69 mm
- Outline dimension: 72.59 x 37.11 x 1 mm
Data sheet
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 2,66
- Resolution
- 360 x 184 px
- Interface
- SPI
- Touch
- No
