ZOBD CAP PLUG 24V – OBD connector cap for ZOBD and ZOBD MINI enclosures, ABS, black Kradex
ID: 1200870
zł10.48
Tax included
zł8.52 tax excl.
ZOBD CAP PLUG 24V is an OBD2 connector cap designed for Kradex ZOBD and ZOBD MINI enclosures, made of black ABS plastic, offered as a set with pins and a lock for mounting 24 V interfaces.
Description
The ZOBD CAP PLUG 24V cap is intended for use with OBD connectors mounted in ZOBD and ZOBD MINI enclosures. Made of black ABS plastic, it provides an aesthetic and safe termination of the 24 V OBD2 interface. The component is sold as a self-assembly kit that includes an OBD2 connector housing, a set of 16 pins, and a locking clip for securing them. It is intended for use in service, diagnostic, and vehicle system applications.
Features
- Type: OBD PLUG 24V
- Material: ABS
- Color: black
- Length: 44.1 mm
- Width: 20.5 mm
- Height: 21.7 mm
1200870
Data sheet
- Colour
- Black
- Materiał
- ABS
- Hermetyczna
- Nie
- Brass bushings
- Nie
- Tightness class
- brak
- Strength class
- none
- Length
- 44,1 mm
- Width
- 20,5 mm
- Height
- 21,7 mm
- Housing type
- OBD
- Flammability class
- none
- ZOBD_Cap.pdf (117,8 kB)
- ZOBD_Cap.step (264,76 kB)
- ZOBD_Cap.dwg (785,86 kB)
- ZOBD_Cap_2000.dwg (14,17 kB)
- ZOBD_Cap.svg (350,11 kB)
- ZOBD_Cap_Complete_documentation.zip (1,69 MB)
- ZOBD_Cap_RS232.pdf (122,72 kB)
- ZOBD_Cap_RS232.step (295,96 kB)
- ZOBD_Cap_RS232.dwg (1,62 MB)
- ZOBD_Cap_RS232_-_2000.dwg (2,29 MB)
- ZOBD_Cap_RS232.svg (370,04 kB)
- ZOBD_Cap_RS232_-_Complete_documentation.zip (2,29 MB)
- ZOBD_Cap_fi5.pdf (177,45 kB)
- ZOBD_Cap_fi5.step (674,89 kB)
- ZOBD_Cap_fi5.dwg (2,03 MB)
- ZOBD_Cap_fi5_-_2000.dwg (3,75 MB)
- ZOBD_Cap_fi5_-Assembly.svg (352,45 kB)
- ZOBD_Cap_fi5_-Base.svg (351,79 kB)
- ZOBD_Cap_fi5_-_Protector.svg (388,18 kB)
- ZOBD_Cap_fi5_-_Complete_documentation.zip (3,3 MB)
- ZOBD_Cap_Plug.pdf (206,76 kB)
- ZOBD_Cap_Plug.step (2,33 MB)
- ZOBD_Cap_Plug.dwg (1,47 MB)
- ZOBD_Cap_Plug_-_2000.dwg (4,71 MB)
- ZOBD_Cap_Plug_-_Assembly.svg (402,62 kB)
- ZOBD_Cap_Plug_-_Plug.svg (500,21 kB)
- ZOBD_Cap_Plug_-Pin_holder.svg (356,5 kB)
- ZOBD_Cap_Plug_-_Pin.svg (334,95 kB)
- ZOBD_Cap_Plug_-_Complete_documentation.zip (3,16 MB)
Manufacturer Kradex Sp. z o.o. ul. Minerska 4 04-506 Warszawa Poland kradex@kradex.com.pl
Responsible person Kradex Sp. z o.o. ul. Minerska 4 04-506 Warszawa Poland kradex@kradex.com.pl
