Firebeetle Covers OLED - module with 128x64 OLED display for FireBeetle
ID: 571908
5906623405848
zł63.00
Tax included
zł51.22 tax excl.
Module with a black and white OLED display with a resolution of 128x64 px, designed for FireBeetle plates. It communicates via the I2C interface. DFRobot DFR0507
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Module with a black and white OLED display with a resolution of 128x64 px, designed for FireBeetle plates. It uses the SH1107 controller, and communication with the module is carried out via the I2C interface. The advantage of OLED displays is that they are extremely bright and legible, and also have high contrast. The board also houses the BMA220 chip, i.e. a digital accelerometer, a joystick and two buttons. The user can also use the GT30L24A3W chip with a library of fonts for displays. Due to its small size, the module will work well in the projects of small IoT devices. Full documentation is available on the product page.
Features
- OLED display:
- Model: UG-2864HLBEG01
- Dimension: 0.96 "
- Blue color
- Interface: I2C
- Resolution: 128x64
- BMA220 accelerometer:
- Resolution: 6-bit
- Measuring range: 2/4/8 / 16g
- I2C interface
- 5-way joystick
- 2 buttons
- GT30L24A3W chip with font library
- Power supply from 3.7 V to 5.5 V
Kit contains
- Firebeetle Covers OLED module
- 2 x 18-pin goldpin male connector
- 2 x 18-pin goldpin female connector
571908
Data sheet
- Screen type
- OLED
- Diagonal (inch)
- 0,96
- Resolution
- 128 x 64 px
- Interface
- I2C
- Touch
- No
