- New
Siglent SPD1305X - 30V/5A laboratory power supply
ID: 1193806
zł1,299.00
Tax included
zł1,056.10 tax excl.
Programmable linear laboratory power supply with a 0-30 V and 0-5 A range, equipped with a 2.8" TFT-LCD screen and real-time voltage waveform display. It supports remote control (SCPI, LabView), save/recall settings, 4-wire measurement, and quiet cooling with a temperature-controlled fan. Thanks to its low noise level, compact housing, and safety features, it is ideal for service, R&D, and precise power supply of electronic systems. Siglent SPD1305X
Description
The Siglent SPD1305X is a programmable linear bench power supply featuring a single output with a voltage range from 0 to 30 V and current up to 5 A. Designed for high precision, reliability, and ease of use, this compact unit is ideal for laboratories and electronics workbenches. It includes a 2.8-inch TFT-LCD display that shows not only live output values but also voltage trend graphs over time, allowing users to monitor output behavior in real time via a graphical interface.
The SPD1305X supports remote control via PC using the EasyPower software, which is compatible with SCPI protocols and LabView drivers. Up to five configuration groups can be saved and recalled for fast setup. A temperature-controlled intelligent fan keeps the unit quiet during low-load operation. With built-in 4-wire sensing, the SPD1305X ensures precise voltage delivery even over resistive connections. Its wide compatibility with AC mains (100/120/220/230 V) makes it suitable for use in almost any country or lab environment.
Features like overload and short-circuit protection make this unit ideal for both service centers and R&D labs. Low ripple and noise levels ensure clean power for sensitive electronics. The front panel includes intuitive buttons for quick setup and timed output control. The unit’s robust build and compact footprint make it easy to integrate into any workspace. The SPD1305X combines the advantages of a classic linear power supply with modern digital functionality, offering unmatched flexibility and safety for engineers, technicians, and electronics enthusiasts.
Key Features
- Output voltage range: 0 to 30 V
- Output current range: 0 to 5 A
- Output type: single, linear
- Display: 2.8" color TFT-LCD
- 4-wire sensing for accurate voltage delivery
- Real-time voltage trend graph display
- Low ripple and noise
- Temperature-controlled intelligent cooling fan
- Overload and short-circuit protection
- Stores and recalls up to 5 configuration sets
- PC communication via USB (EasyPower software)
- Supports SCPI and LabView protocols
- Input voltage compatibility: 100/120/220/230 V
- Dimensions: 154.6 × 144.5 × 280 mm
- Weight: 5.5 kg
Kit contains
- Siglent SPD1305X power supply
- AC power cable
- USB cable
- Warranty card
1193806
Data sheet
- Output voltage
- 0-30 V
- Output current
- 5A
- Number of channels
- 1
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
