zł2,926.02 tax excl.
2-channel portable digital oscilloscope with a frequency band of 100 MHz. It uses a single ADC with a maximum sampling rate of 1 GSa/s and a memory module with a depth of 12 Mpts. Siglent SHS810X
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
An oscilloscope is an indispensable tool in electronic laboratories and industries, enabling the analysis and measurement of electrical signals. The Siglent SHS810X offers a bandwidth of 100 MHz, providing precise examination of medium-frequency signals. With the ability to divide a single ADC converter, it can achieve a maximum sampling frequency of up to 1 GSa/s per channel, allowing for fast and accurate measurements. It features 2 analog oscilloscope channels and 1 multimeter channel, increasing its versatility.
The oscilloscope's memory depth is up to 12 Mpts/CH in single-channel mode, enabling the storage and analysis of a larger amount of data. Additionally, the oscilloscope can capture waveforms at a rate of up to 400,000 wfm/s in sequence mode, allowing for rapid event registration. With various triggering sources such as edge, slope, and pulse width, it enables precise detection and analysis of signals. Moreover, it has the function of triggering and decoding serial interfaces, facilitating the analysis of I2C, SPI, UART, CAN, LIN communication.
The data logger allows for the recording of measurement data and logging, which is useful for analyzing long-term phenomena. The oscilloscope is also equipped with a USB Host and USB Device interface, facilitating data transfer and communication with other devices. It features a 5.6-inch TFT-LCD screen and is portable and easy to use. Therefore, it is the perfect tool for both professionals and hobbyists who need a precise and reliable tool for analyzing electrical signals.
Features
- Bandwidth: 100 MHz
- Sampling Rate: 1 GSa/s
- Channels: 2 analog oscilloscope channels, 1 multimeter channel
- Memory Depth: 6 Mpts/CH (dual-channel mode), 12 Mpts/CH (single-channel mode)
- Waveform Capture Rate: 100,000 wfm/s (normal mode), 400,000 wfm/s (sequence mode)
- Trigger Types: edge, slope, pulse width, window, interval, dropout, pattern, video
- Serial Interfaces Triggering and I2C, SPI, UART, CAN, LIN decoding
- Data Logger
- USB Host, USB Device
- Maximum Input Voltage (Oscilloscope): CAT II 300, CAT II 30 Vrms, CAT II 300 Vrms
- Maximum Input Voltage (Multimeter): CAT III 300 Vrms
- 5.6-inch TFT-LCD Display (640x480)
- Weight: 1.75kg
Kit contains
- Siglent SHS810X Oscilloscope
- 6900 mAh Battery
- 2 x 100 MHz Oscilloscope Probes
- 2 x Adapters (1 x SCD600MA / 1 x SCD10A)
- 1 x Set of Multimeter Probes
- 1 x Power Adapter/Charger
- 1 x USB Cable
Data sheet
- Type of oscilloscope
- Portable
- Bandwidth
- 100 MHz
- Sampling rate
- 1 Gsps
- Memory depth
- 12 Mpts
- Number of channels
- 2
