This breakout board, the ultimate companion for the VLSI VS1053B DSP codec chip, can decode a wide variety of audio formats MP3, AAC, Ogg Vorbis, WMA, MIDI, FLAC, WAV (PCM and ADPCM); it can be used to record audio in both PCM (WAV) and compressed Ogg Vorbis. 8 GPIO pins can be used for lighting up small LEDs or reading buttons. Adafruit 1381

24h
Available
Available quantity: 2
Kamami is the official distributor of Adafruit modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.

Description

This breakout board is the ultimate companion for the VLSI VS1053B DSP codec chip. The VS1053 can decode a wide variety of audio formats such as MP3, AAC, Ogg Vorbis, WMA, MIDI, FLAC, WAV (PCM and ADPCM). It can also be used to record audio in both PCM (WAV) and compressed Ogg Vorbis. You can do all sorts of stuff with the audio as well such as adjusting bass, treble, and volume digitally. There is also 8 GPIO pins that can be used for stuff like lighting up small LEDs or reading buttons.

All this functionality is implemented in a light-weight SPI interface so nearly any microcontroller can play audio from an SD card. Theres also a special MIDI mode that you can boot the chip into that will read classic 31250 kbaud MIDI data on a UART pin and act like a synth/drum machine - there are dozens of built-in drum and sample effects! But the chip is a pain to solder, and needs a lot of extras. Thats why we spun up the best breakout, perfect for use with an Arduino but also good for other microcontrollers that just dont have the computational power to decode MP3s.

The breakout is slim enough to fit on a breadboard with 1 row of holes left over for wiring. Theres 3.3V and 1.8V regulators onboard with ferrite beads and analog filtering for quality analog output. Theres a microphone input port that you can wire up a line-in or mic to and record compressed audio. All 8 GPIO are broken out and they all have built in 100K pulldowns, simply connect your button from the GPIO pin to 3.3V for an active-high connection. Youll likely want to play music from a microSD card so we added a holder on-board. And since we know so many of our customers use 5 V microcontrollers like the Arduino, we made the interface pins all 5V compliant with level shifters so you can use the chip at 3V or 5V power/logic!

Features

  • Dimensions: 27.72mm / 1.09" x 58.08mm / 2.28"
