3-channel relay module for Jetson Nano - Waveshare 19075
ID: 583765
5906623422388
zł64.38
Tax included
zł52.34 tax excl.
The module is equipped with three 5A / 250VAC relays controlled by digital outputs. Relay contacts are led out to ARK screw terminals. Designed to work with NVIDIA Jetson Nano. Waveshare 3-CH Relay for Jetson Nano
Description
Module with electromechanical relays designed to work with NVIDIA Jetson Nano. It is equipped with three 5A / 250VAC relays controlled by digital outputs, and the relay contacts are led out to the ARK screw terminals. The module connects to the minicomputer via a 40-pin GPIO connector. The set includes an acrylic pad isolating the plate from Jetson Nano. The module uses optocouplers that prevent interference from high voltage circuits. There are also LED indicators on the board that indicate the operating status of the relays.
| 1. GPIO 40-pin header | 5. Relay LED indicators |
| 2. Relay screw terminals | 6. Power supply indicator |
| 3. Relay components | 7. Relay control pin selection jumpers |
| 4. Optocouplers |
Pinout description
Features
- 40-pin GPIO connector, plugs directly into Jetson Nano
- Number of channels: 3
- Maximum load: ≤5A 250VAC or ≤5A 30VDC
- Optocoupler isolation, prevents interference from high voltage circuits
- Indicators for monitoring the operating status of the relay
- The control pins can be configured with jumpers
- Acrylic bottom panel isolating the Jetson Nano from the expansion module
- Dimensions: 100 x 79 mm
Kit contains
- 3-CH Relay for Jetson Nano module
- Insulating washer
- Set of screws
583765
Data sheet
- Output current
- 5A
- Number of channels
- 3
- Executive element
- Przekaźnik
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
