MiniWare TS1C - digital station with cordless soldering iron (B02 tip)

Description

Station with a 36 W cordless soldering iron. The base has a built-in OLED display with a resolution of 128 x 64 pixels. The soldering iron is temperature adjustable from 100°C to 400°C and has many built-in features such as auto sleep, power off and intelligent compensation for good temperature control and intuitive operation. The dynamic circuit detection system ensures safety and protects the circuits from damage.

The TS1C station is equipped with an OLED display, which is used to present the current operating parameters. The soldering iron uses a new tip attachment for better grip and easy replacement. It is powered thanks to the built-in supercapacitor, which is charged by the station or, if you need fast charging, via the USB type C connector. The base can be powered via the USB type C socket with 20V voltage with a power of 45 W using the Power Delivery standard. The soldering iron is easy to assemble and disassemble, and when unfolded it takes up much less space and is easier to transport. The configuration of the device is done using buttons and an encoder or using a smartphone and Bluetooth communication. The user can also connect the soldering iron to a computer and easily update the firmware using the DFU function, which gives access to the latest functionalities.

Features

Kit contains
