Fuse Breakout Kit - module with a fuse
ID: 584198
5906623420810
zł36.06
Tax included
zł29.32 tax excl.
Module with a 5x20 mm fuse with a working voltage up to 250 VAC and a current of 500 mA. A kit for self-assembly. SparkFun KIT-15702
Description
Module with a 5x20 mm fuse with a working voltage up to 250 VAC and a current of 500 mA. It allows you to add a current protection in the project. The input voltage is connected via a DC connector or a screw connection, and the output via a 2-pin screw connection. The fuse is placed in a socket, thanks to which it can be easily replaced in the event of damage or the need to place an element with different operating parameters. Full documentation and examples of use are available on the product page.
Features
- Fuse 5x20 mm 250VAC/500mA
- Fuse holder 5x20 mm
- Screw connections or DC coupler
- Dimensions: 13 x 65 mm
Kit contains
- PCB board
- 2 x 5mm fuse contacts
- Fuse 5x20mm 250VAC/500mA
- 2 x 5mm screw connection
- DC connector
584198
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
