Development board with 7-inch touch display and Wi-Fi 6 – Waveshare 32510
ID: 1201080
5902186330252
zł226.92
Tax included
zł184.49 tax excl.
Integrated board with ESP32-P4 and ESP32-C6-MINI and a 7-inch IPS touch screen with a resolution of 1024 × 600 intended for advanced IoT, AIoT, HMI and multimedia processing applications. Thanks to Wi-Fi 6 support, many industrial interfaces and strong security functions, it constitutes a versatile solution for next-generation embedded systems.
Description
Advanced development board based on the ESP32-P4-Core module with the ESP32-P4 microcontroller and the ESP32-C6-MINI module providing Wi-Fi 6 and Bluetooth 5 LE connectivity. The integrated 7-inch IPS touch display with a resolution of 1024 × 600 pixels and a touch panel with a GT911 controller supports up to 5 simultaneous touch points. The device is designed for applications in HMI interfaces, image and sound processing, industrial communication and AIoT uses. Support for MIPI DSI and MIPI CSI, built-in ES8311 audio codec, ES7210 echo cancellation chip, UART, I2C, CAN and RS485 interfaces, as well as USB ports (OTG and UART) ensure full functionality in embedded projects. Data security is provided by Secure Boot, Flash encryption and cryptographic accelerators.
Properties
- Microcontroller: ESP32-P4 (dual-core + single-core, RISC-V, 240 MHz)
- Wireless communication: Wi-Fi 6 (2.4 GHz), Bluetooth 5 LE (ESP32-C6-MINI, SDIO)
- Memory: 32 MB Flash, 32 MB PSRAM
- Display: 7" IPS, 1024 × 600, RGB565/RGB666/RGB888, brightness 350 cd/m², contrast 600:1, 160° viewing angle
- Touch panel: capacitive, GT911, 5-point touch support
- Audio interfaces: ES8311 codec, ES7210 echo cancellation chip, two MEMS microphones, speaker connector
- Communication interfaces: CAN, RS485, UART, I2C (PH2.0 connectors)
- Multimedia interfaces: MIPI CSI (camera), MIPI DSI (LCD), microSD slot (SDIO 3.0)
- Security: Secure Boot, Flash Encryption, TRNG, access separation, key manager
- Power and ports: USB Type-C (debug, power), USB OTG (Type-A), power switch
- RTC: CR1220 connector, real-time clock backup
- Additional connectors: GPIO 2×12 (17 I/O lines), SH1.0 4-pin (RTC), PH2.0 for communication
- Board dimensions: 164 × 97 mm
- Display dimensions: 164.28 × 99.17 mm
Included
- ESP32-P4-WIFI6-Touch-LCD-7B board x1
- Dual-plug USB Type-A cable x1
- USB Type-A to Type-C cable (approx. 1 m) x1
- Speaker x1
- SH1.0 4-pin cable (approx. 150 mm) x1
- PH2.0 12-pin cables (approx. 200 mm) x2
- PH2.0 4-pin cables (approx. 200 mm) x4
1201080
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
