Development board with Espressif ESP32-S3-WROOM-1 module. The module has built-in 8 MB Flash memory and 8 MB PSRAM and offers WiFi and Bluetooth LE wireless communication. Espressif Systems ESP32-S3-DevKitC-1-N8R8

1 weeks
Awaiting delivery

Description

Development board with the versatile Espressif ESP32-S3-WROOM-1 module, which will allow you to implement various projects using wireless communication. It provides not only reliable connectivity, but also extensive programming and interaction capabilities with other devices. The module has as much as 8 MB of Flash memory, which allows you to store applications and data. Additionally, 8 MB of PSRAM allows you to effectively manage large amounts of data, which is extremely useful in advanced projects. ESP32-S3-WROOM-1 has an integrated WiFi 802.11 b/g/n and Bluetooth transceiver that supports the BLE 5 and Bluetooth Mesh standards. This is an ideal solution for IoT projects that require network access and communication with other devices.


GPIO pins on the board allow for full flexibility in interacting with external devices. The module supports analog inputs and I2C, UART and SPI interfaces, which opens the door to unlimited design possibilities. Programming the module is extremely simple, thanks to the micro USB connector, which is used for programming and powering the device. This means you can start working on your project quickly. In addition, the board is equipped with a 3.3 V voltage stabilizer with appropriate current efficiency, which ensures a stable power supply. Additionally, the RGB LED enables simple and effective signaling of the device status or communication with the user.

The ESP32-S3-WROOM-1 module is a solution that combines performance, extensive memory, integrated communication modules and ease of programming. It offers great possibilities in the field of IoT systems and can be programmed using Arduino IDE, ESP-IDF, MicroPython. Regardless of the type of project, this module gives you the tools to implement applications that use advanced technologies.

Features

  • 240 MHz dual-core Xtensa 32-bit LX7 processor
  • Integrated 512 kB SRAM, 384 kB ROM, 8 MB Flash, 8 MB PSRAM
  • Wi-Fi 2.4 GHz - 802.11b/g/n
  • Bluetooth LE 5, Bluetooth Mesh
  • PCB antenna
  • Voltage stabiliser 3.3V
  • Optimised power supply for low power consumption
  • Power supply: USB micro B
  • CH343P USB-UART converter and CH334F HUB controller
  • Full-Speed USB OTG interface, LCD interface (8-bit RGB/8080/6800 serial), DVP camera interface (8-bit - 16-bit)
  • 45 GPIO pins, including 3 x UART, 4 x SPI, 2 x I2C, PWM, 12-bit ADC, 14 x touch, 2 x I2S
  • Dimensions: 63.3 x 25.4 mm
