Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 (with soldered connectors)
search
  • Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 (with soldered connectors)
  • Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 (with soldered connectors) - top view
  • Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 (with soldered connectors) - bottom view
  • Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 (with soldered connectors)
ID: 569353
zł152.38
Tax included

zł123.89 tax excl.

Adafruit HUZZAH32 is a development board with a built-in WiFi ESP32 module. Processor frequency: 240 MHz, Li-Pol battery charging system. The board has soldered goldpin connectors. Adafruit 3591

6 weeks
On request
Kamami is the official distributor of Adafruit modules and development kits. All boards of this brand in our offer are original and come directly from the manufacturer.



Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

Adafruit HUZZAH32 is a new development board from Adafruit with a built-in WiFi ESP32 module. The heart of the board is the ESP32 module with a microcontroller clocked at 240 MHz and logic working in the voltage range from 0 to 3.3 V. The programming of the board is extremely simple thanks to the Arduino IDE environment providing a quick start for projects related to IoT technology.

Attention!


The microcontroller lines tolerate the 3.3V voltage. Applying higher voltage to these lines can damage the microcontroller.

Built-in lithium-polymer battery connector and charger module enable connection of a 500 mAh Li-Pol battery . The battery is charged via the mounted USB connector. In addition, the board has a connection between the battery and one of the analog inputs, which allows detecting the battery charge and battery discharge signaling. The board has soldered goldpin connectors (there is also a version without soldered connectors - Adafruit HUZZAH32 - Feather module with Wi-Fi ESP32 )

properties

  • Equipped with Espressif WiFi ESP32 module
    • Operating frequency: 240 MHz
    • Built-in 520 KB SRAM memory
    • Built-in WiFi 802.11 b / g / n module
    • Built-in Bluetooth module (classic and BLE)
    • 4 MB FLASH memory
    • Built-in antenna
    • Hall sensor
    • Operation of touch buttons (maximum 10)
    • A 32 kHz crystal oscillator
    • 3 UART (2 configured by default, 1 for debugging)
    • 3 SPI (one configured by default)
    • 12 ADC inputs
    • 2 I2S Audio
    • 2 DACs
    • Each GPIO pin has the ability to generate a PWM signal
  • OpenOCD for debugging
  • Support for handling SD memory cards
  • Possibility of powering from Li-Pol (JST) battery or USB
  • 4 mounting holes
  • Dimensions: 50 x 23 x 15.6 mm
  • Weight: 8.4 g
569353

Data sheet

Microcontroller
ESP32
Flash memory
4 MB
Number of I/O
21
Ethernet
none
WiFi/BT module
Yes
Bluetooth module
Yes
MicroSD slot
No
Length
50mm
Width
23 mm
USB connector type
microUSB type B
