FeatherWing - 8-channel PWM module / servo controller
ID: 560926
5906623429080
zł55.40
Tax included
zł45.04 tax excl.
This module enables the Feather series range to be expanded with 8 12-bit PWM outputs that can be used, for example, to control servos or LED diodes. Adafruit 2928
Description
This module enables the Feather series range to be expanded with 8 12-bit PWM outputs that can be used, for example, to control servos. Using the appropriate connectors ( 16-pin connector and 12-pin connector ), the Feather tile module can be easily attached.
Because the FeatherWing controller uses the I2C interface (SDA and SCL pins), it can work with all Feather baseplates (eg based on ATmega32u4, ATSAM M0, ESP8266). You can also attach several FeatherWing controllers to one I2C bus.
properties
- 8 PWM outputs
- Configurable I2C address (possibility to connect up to 62 FeatherWing controllers to one I2C bus)
- The frequency of PWM signals up to 1.6 kHz
- 12-bit PWM signal resolution
- Push-pull outputs or an open drain
- Protection against reverse polarity of the supply voltage
- The possibility of mounting an additional capacitor at the power input
- 220 Ohm resistors on the output lines
- Includes two 3x4 goldpin connectors, screw power connector, single-row goldpin connectors for connection to the Feather plate
- Logic level 3.3 V
- Possibility to power the server with voltage up to 6 V
- Size: 50.8 x 22.9 x 1.6 mm
- Weight: 3.9g
560926
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
