Twilight switch 16A 250VAC – Finder 11.31.0.024.0001
ID: 1195579
8012823362595
zł262.51
Tax included
zł213.42 tax excl.
Finder 11.31.0.024.0001 is a twilight switch with a light sensor, designed for automatic lighting control in low-voltage 24 V installations. It is suitable for both outdoor and indoor systems, offering simple adjustment of the switching threshold and high operational durability.
Description
The Finder 11.31.0.024.0001 twilight switch module is designed for automatic lighting control based on ambient light intensity. It features a single SPST-NO relay output rated at 16 A at 250 V AC. Suitable for mounting on a standard DIN rail in electrical distribution panels. The switch-on delay is 15 seconds and the switch-off delay is 30 seconds to prevent unintended operation due to momentary changes in light levels. The device is powered by 24 V AC/DC and includes an external light sensor with adjustable sensitivity.
Specifications
- Module type: twilight switch
- Output: 1× SPST-NO
- Output rating: 250 V AC / 16 A
- Supply voltage: 24 V AC / 24 V DC
- Switch-on delay: 15 s
- Switch-off delay: 30 s
- Operating temperature: –20 °C to +50 °C
- Electrical durability: 100,000 cycles
- Mounting: DIN rail
- Dimensions: 17.5 × 88.8 × 60.8 mm
- Protection rating: IP 20
1195579
Data sheet
- Output current
- 16 A
- Number of channels
- 1
- Executive element
- Twilight switch
- Coil voltage
- 250 VAC
