Interface relay 24V 8A Finder 38.52.7.024.0050
ID: 1195590
5906623497812
zł71.36
Tax included
zł58.02 tax excl.
Finder 38.52.7.024.0050 is a relay interface module with a 24 V DC coil, equipped with two changeover contacts (DPDT) with a load capacity of 8 A. It is designed for DIN rail mounting and features screw terminals for easy installation.
Description
Finder 38.52.7.024.0050 is a relay interface module equipped with a 24 V DC coil and two changeover contacts (DPDT, 2 Form C) with an 8 A load capacity. The relay is designed for DIN rail mounting and features screw terminals, ensuring easy installation. With high-quality construction and silver-nickel (AgNi) contacts, the module offers durability and reliability in various industrial applications. Finder 38.52.7.024.0050 is a versatile general-purpose relay, ideal for industrial automation, control systems, and applications requiring reliable electrical load switching.
Specifications
- Contact configuration: DPDT (2 Form C)
- Contact rating: 8 A
- Maximum switching voltage: 400 V AC
- Maximum switching power: 3200 VA
- Coil voltage: 24 V DC
- Coil current: 19.5 mA
- Coil type: Non-Latching
- Operate time: 8 ms
- Release time: 10 ms
- Must operate voltage: 19.2 V DC
- Must release voltage: 2.4 V DC
- Operating temperature: -40°C ~ 70°C
- Mounting: DIN rail or panel mount
- Contact material: Silver-Nickel (AgNi)
- Approvals: CE, CSA, cURus, EAC, RINA, UKCA
- Termination style: Screw terminals
1195590
Data sheet
- Output current
- 8 A
- Number of channels
- 2
- Executive element
- Interface relay
- Coil voltage
- 24 VDC
Manufacturer FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland finder.pl@findernet.com
Responsible person FINDER POLSKA SPÓŁKA Z OGRANICZONA ODPOWIEDZIALNOŚCIĄ Logistyczna 27, Sady 62-080 Tarnowo Podgórne Poland formularz kontaktowy na stronie osoby odpowiedzialnej
