Finder 66.82.8.230.4000 - Power relay 2P 30 A 230 VAC
ID: 1200972
zł51.70
Tax included
zł42.03 tax excl.
Finder 66.82.8.230.4000 relay with 30 A contact current and 230 V AC coil voltage is suitable for automation systems and industrial applications requiring reliable switching of high loads. Equipped with Faston 250 connectors and designed for panel mounting.
Description
Power relay with two changeover contacts designed for panel mounting using Faston 250 connectors. Powered by 230 V AC, it operates in the range from 184 V to 253 V with a power consumption of 3.6 VA. Equipped with an AC coil and contacts made of AgSnO₂ alloy, it enables control of loads up to 30 A at 250 V AC. The dielectric strength between the coil and contacts is 6 kV. The electrical durability of the relay reaches 100,000 cycles, and the operating temperature range is from -40°C to +70°C. The product is dedicated to industrial and automation applications where high reliability and switching performance are required.
Properties
- Type: power relay
- Contact configuration: 2 changeover (2P)
- Rated contact current: 30 A
- Rated contact voltage: 250 V AC
- Coil: AC, 230 V
- AC supply voltage range: 184...253 V
- Coil power consumption: 3.6 VA
- Coil resistance: 4000 Ω
- Coil current: 15.7 mA
- Holding voltage: 184 V
- Drop-out voltage: 46 V
- Dielectric strength (coil/contacts): 6 kV
- Electrical durability: 100,000 cycles
- Contact type: AgSnO₂
- Connectors: Faston 250
- Mounting: panel mounting
- Operating temperature: -40...70°C
- Dimensions: 33.5 × 31 × 68.5 mm
1200972
Data sheet
- Output current
- 30 A
- Number of channels
- 2
- Executive element
- Przekaźnik
- Coil voltage
- 230 VAC
