Miniature PCB relay 12A 24VDC Finder 40.31.9.024.0000
search
  • Miniature PCB relay 12A 24VDC Finder 40.31.9.024.0000
ID: 1201334
zł14.18
Tax included

zł11.53 tax excl.

Miniature relay Finder 40.31.9.024.0000 with one 12 A changeover contact and a 24 V DC coil designed for PCB mounting and 95 series sockets. It provides high durability, safe insulation parameters, and compact dimensions for use in industrial automation and electronics.

24h
Available
Available quantity: 10

Description

The miniature relay Finder 40.31.9.024.0000 is designed for mounting on printed circuit boards with a 3.5 mm pitch and for use with 95 series sockets. It is equipped with one 12 A changeover contact and a DC 24 V coil operating in a range from 17.5 to 36 V. The coil power consumption is 0.65 W, with a resistance of 900 Ω and a current of 27 mA. The holding voltage is 9.6 V, and the drop-out voltage is 2.4 V. The construction provides coil-to-contact insulation of 6 kV and an 8 mm insulation clearance. The relay is made in the standard RT II version, with an operating temperature range from -40°C to +85°C, and features electrical durability of 200,000 cycles.

Properties

  • Coil powered by DC 24 V
  • DC supply voltage range: 17.5–36 V
  • Rated coil power: 0.65 W
  • Coil resistance: 900 Ω
  • Current consumption: 27 mA
  • Holding voltage: 9.6 V
  • Drop-out voltage: 2.4 V
  • Contact configuration: 1 changeover contact
  • Rated contact current: 12 A
  • Rated contact voltage: 250 V AC
  • Coil/contact insulation: 6 kV
  • Insulation clearance: 8 mm
  • Electrical durability: 200,000 cycles
  • Dimensions: 12.4 × 25 × 29 mm
  • Operating temperature: -40°C to +85°C
  • Pin pitch: 3.5 mm
  • Pin length: 5.2 mm (for sockets)
  • Cadmium-free contacts
  • Version: Standard (RT II)
1201334

Data sheet

Output current
12 A
Number of channels
1
Executive element
Przekaźnik elektromagnetyczny
Coil voltage
24 VDC
