Pololu 1617 - MPL115A1 Barometric Pressure Sensor Breakout Board
ID: 196163
MPL115A1 Barometric Pressure Sensor Breakout Board
MPL115A1 Barometric Pressure Sensor Breakout Board
The MPL115A1 is a MEMS digital barometer that takes barometric pressure readings with a range of 50 to 115 kPa and an accuracy of ±1 kPa and provides the results over an SPI interface. This sensor also doubles as a temperature sensor that operates from -40 to 105 °C. The breakout board’s pins are spaced 0.1" apart making it easy to use with standard breadboards and 0.1" perfboards.
 |
Overview
The MPL115A1 MEMS digital barometer carrier board from SparkFun takes ±1 kPa accurate pressure readings with a range of 50 to 115 kPa. The barometric pressure sensor makes the readings available via SPI. The pressure sensor’s average current consumption is 10ěA at one measurement per second. The sensor doubles as a temperature sensor that operates from -40 to 105 °C. The breakout board’s pins are spaced 0.1" apart making it easy to use with standard breadboards and 0.1" perfboards.
See page 3 of the MPL115A1 datasheet (228k pdf) for information on how to take readings from this barometric pressure and temperature sensor. SparkFun also provides AVR ATMega328 C code for interfacing with the MPL116A1 (17k zip).
Features
- Wide supply voltage range from 2.4 to 5.5 V
- -40 to 105 °C thermometer range
- 1 kPa pressure reading accuracy
- Low power consumption
|
|
