The ArduCam MT9D111 2MPx camera module

Description

The ArduCam MT9D111 2MPx camera module is based on a matrix with the MT9D111 chip. It allows you to record single images and video recording by AVR microcontrollers ( ARDUINO boards), STM32 , Raspberry Pi single board computers ( Raspberry Pi 3 model B + , Raspberry Pi 3 model B , Raspberry Pi 2 model B , Raspberry Pi 1 model B + ) or BeagleBone Black .

The transmission speed of JPEG image data at the full resolution of 1600 x 1200 pixels is 15 fps. It is equipped with a lens whose format is 1 / 3.2 ''. The camera module works with 3.3 V and communicates via a parallel interface.

properties

• Matrix MT9D111, CMOS, 1 / 3.2 ''
• Resolution: 1600 x 1200 pixels (2 MPx)
• Pixel size: 2.8 x 2.8 μm
• Integrated auto-focus
• Built-in JPEG encoder - working in real time
• Built-in A / C converter with a resolution of 10 bits
• Sensitivity: 1.0 V / lux-sec (for 550 nm)
• SNRMAX: 42 dB
• Built-in LDO voltage regulator
• JPEG 4: 2: 2 and 4: 2: 0
• Speed:
  • 2160 x 1200 pixels: 15 fps
  • 800 x 600 pixels: 30 fps
• Work voltage:
  • I / O outputs: 1.7 V to 3.6 V
  • Core: 1.7 V to 1.9 V (1.8 V nominal)
  • Analogue circuits: 2.5 V to 3.1 V (nominal 2.8 V)
