USB tester for precise monitoring of the performance of devices connected to the USB port. It can recognise fast charging modes and monitor and convert PD modes. It has built-in Bluetooth communication and a metal housing. Fnirsi FNB48P

24h
Available
Available quantity: 7
Kamami is the official distributor of Fnirsi measuring tools. All products of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The USB tester is a device for the precise measurement of voltage and current. It offers multiple functionalities to monitor the performance of devices connected to the USB port. The tester can identify fast charging modes such as QC2.0, QC3.0, Huawei FCP, Huawei SCP, Samsung AFC, VOOC/WARP, SuperVOOC and MTK-PE. The device also monitors Power Delivery mode operation and performs PD protocol conversion.


1. Micro USB (PC)        6. USB typu C Out
2. Button OK 7. PD COM
3. Button BACK  8. USB 3.0 In
4. USB typu C In            9. USB typu A Out
5. Micro USB In

The tester has a 1.77" TFT LCD display and 2 control buttons. It uses an internal ADC converter, allowing highly accurate measurements. It can monitor input voltage and current, as well as power. It also displays the internal resistance value. The USB tester can measure temperature and flowing charge and energy. This data is stored along with a time stamp. Via the micro USB (PC) port, the user can update the software. An interesting feature, rarely available in this type of device, is the possibility to communicate via Bluetooth and view the measurements on a mobile device, for example. It is closed in metal case. The USB tester can serve as a reliable diagnostic tool in a variety of applications, including electronics, industry or home.

Features

  • Precise voltage and current measurements
  • Recognition of fast charging modes: QC2.0, QC3.0, Huawei FCP, Huawei SCP, Samsung AFC, VOOC/WARP, SuperVOOC and MTK-PE
  • Monitoring of Power Delivery operation
  • PD protocol conversion
  • Data storage
  • Software update
  • TFT LCD display 1.77"
  • 2 control buttons
  • USB Type A connector
  • USB type A, micro USB, USB type C socket
  • Internal 16-bit ADC converter
  • Input voltage: 3.8 to 24 V
  • Input current: 0 to 6.5 A
  • Input power: 156 W
  • Internal resistance: 0 to 10 kΩ
  • D+/D- voltage: 0 to 3.3 V
  • Temperature measurement
  • Capacity: 0 to 10000 mAh
  • Energy: 0 to 10000 Wh
  • Operating time recording
  • Independent power supply
  • PD physical switch
  • Display orientation detection
  • Bluetooth communication
  • Metal case
  • Dimensions: 77 x 38,6 x 14 mm
