4.3" IPS display with a 5-point capacitive touch panel, DSI interface, and 480 × 800 resolution. Designed for Raspberry Pi, ESP32-P4, RK3506, RK3576, and embedded systems requiring a compact touch display. Waveshare 4.3-DSI-TOUCH-A

6 weeks
Awaiting delivery
Kamami is the official distributor of Waveshare displays, accessories and modules.

Description

The 4.3-DSI-TOUCH-A is a compact 4.3" IPS display equipped with a capacitive touch panel supporting up to 5 touch points. The module uses a 2-lane MIPI DSI interface and a 480 × 800 pixel resolution in portrait orientation by default. The IPS panel provides a 170° viewing angle, accurate color reproduction, and stable image quality from different viewing positions. The display is designed for use with Raspberry Pi, RK3506, RK3576, ESP32-P4 platforms, and Linux or Android-based systems.



The display features 6H hardness toughened glass and optical bonding technology, reducing reflections and improving image readability. Touch functionality is handled by the GT911 controller communicating via the I2C interface, while image processing is managed by the ST7701S display driver. The module supports software backlight adjustment and is compatible with Raspberry Pi OS, Ubuntu, Debian, Buildroot, and Android systems. The aluminum enclosure allows integration with HMI applications, control panels, embedded systems, and IoT devices.


Features

  • Display diagonal: 4.3"
  • Display type: IPS LCD
  • Resolution: 480 × 800
  • Display interface: MIPI DSI 2-lane
  • Default orientation: portrait
  • Viewing angle: 170°
  • Touch panel: 5-point capacitive
  • Touch interface: I2C
  • Touch controller: GT911
  • Display driver: ST7701S
  • Panel technology: optical bonding
  • Glass hardness: 6H
  • Brightness: 500 cd/m²
  • Contrast ratio: 1000:1
  • Supported systems: Raspberry Pi OS, Ubuntu, Debian, Android, Buildroot
  • Compatibility: Raspberry Pi, ESP32-P4, RK3506, RK3576
  • Backlight adjustment: software controlled
  • Enclosure material: aluminum
  • Module dimensions: 116.50 × 68.90 mm
  • Active area: 93.60 × 56.16 mm
  • Weight: 115 g

Kit includes

  • 4.3-DSI-TOUCH-A display
  • 12 cm MIPI DSI cable
  • MX1.25 2PIN to 2.54 3PIN cable 110 mm
  • FFC 22PIN cable ~200 mm
  • FFC 22PIN cable ~100 mm
  • MX1.25 2PIN to MX1.25 4PIN cable ~150 mm
  • Mounting standoffs set
1205319

Data sheet

Screen type
IPS
Diagonal (inch)
4,3
Resolution
480 x 800 px
Interface
MIPI-DSI
Touch
Yes
