HDMI LCD IPS display 10.1" (G) with touch panel and enclosure - Waveshare 21021
ID: 588239
5906623426195
zł542.06
Tax included
zł440.70 tax excl.
IPS 10.1" LCD display with touch screen. Equipped with HDMI interface for image display and USB for touch screen operation. Resolution 1920x1200 pixels. Waveshare 10.1inch HDMI LCD (G) (with case) (EU)
Description
IPS 10.1" LCD display with a touch screen placed in a case made of ABS. It is equipped with an HDMI interface for displaying the image and USB for operating the touch screen. It offers a resolution of 1920x1200 pixels and has built-in speakers and audio output Jack. It can work with the Raspberry minicomputer Pi, Jetson Nano, PC, Xbox360, PS4 and Switch The display supports a wide range of operating systems: from Raspbian, Ubuntu, Kali, WIN10 IoT for Raspberry Pi to Windows 10, 8.1, 8, 7 for PC. Full documentation with examples of use is available on the product page.
Features
- Diagonal: 10.1"
- Resolution: 1920 x 1200 px
- Matrix type: LCD IPS
- HDMI connector
- 160 ° wide viewing angle
- Capacitive touch screen (10 points)
- Touch screen interface: USB
- Brightness and contrast can be adjusted
- Tempered glass panel
- Audio output: 3.5mm Jack, HiFi speakers
- ABS housing
- Works with Raspberry Pi (all versions), Jetson Nano, PC, Xbox360, PS4, Switch
- Dimensions: 263.45 x 182.45 mm
Kit contains
- 10.1inch HDMI LCD (G) with case
- 12 V power supply
- HDMI cable
- HDMI to Micro HDMI adapter
- USB-A to Micro-B cable
- Stand
- Instruction
588239
Data sheet
- Screen type
- IPS
- Diagonal (inch)
- 10,1
- Resolution
- 1920 x 1200 px
- Interface
- HDMI
- Touch
- Yes
