74LVC1G126GV.125
search
  • 74LVC1G126GV.125
ID: 571586
5902186304413
zł1.89
Tax included

zł1.54 tax excl.

74LVC1G126GV,125 is a compact logic buffer with a 3-state output, optimized for low-voltage digital applications. With fast switching, low power consumption, and a wide operating voltage range, it is well-suited for embedded systems, data transmission, and consumer electronics.

24h
Available
Available quantity: 1597

Description

Single-channel buffer/driver with a 3-state output from the LVC family, designed for use in low-voltage digital systems powered from 1.65 V to 5.5 V. It functions as a non-inverting buffer with output control via an OE (Output Enable) line. Featuring ultra-low quiescent current and fast switching time, the device is ideal for embedded, portable, and communication applications. Supplied in a compact SC‑74A (SOT‑753) surface-mount package.

Features

  • Function: non-inverting buffer with 3-state output
  • Logic family: LVC
  • Number of channels: 1
  • Input: single-ended
  • Output: 3-state (controlled by OE signal)
  • Supply voltage: 1.65 V to 5.5 V
  • Output current: ±32 mA
  • Quiescent current: 100 nA
  • Operating current: typ. 4 μA, max. 200 μA
  • Propagation delay: 2.3 ns @ 2.7 V / 2.0 ns @ 3.3 V / 1.7 ns @ 5 V
  • Mounting style: SMD/SMT
  • Package: SC‑74A (SOT‑753), 3.1 mm × 1.7 mm × 1.0 mm
  • Operating temperature: –40 °C to +125 °C
  • Technology: CMOS
  • RoHS compliant
