NINA B306 BLE module board based on the nRF52840 microcontroller with CortexM4F core (64 MHz, 1 MB Flash, 256 kB RAM). Equipped with sensors - 9-axis IMU, temperature, pressure, humidity, light, colour, gesture and microphone. Arduino ABX00069

24h
Available
Available quantity: 7
Kamami is the official distributor of Arduino development kits and accessories. All boards of this brand in our offer are original and come directly from the manufacturer.

Description

The Arduino Nano 33 BLE Sense is a board with a NINA B306 BLE module based on the nRF52840 microcontroller with CortexM4F core equipped with 1 MB flash memory, 256 kB RAM. It allows clocking up to 64 MHz. The board has built-in Bluetooth 5.0 communication and sensors - 9-axis IMU, temperature, pressure, humidity, light, colour, gesture and microphone. The module has two 15-pin connectors equipped with GPIO, SPI, I2C, PWM, USART, DAC and ADC.

Attention!

The Arduino Nano 33 BLE Sense only supports 3.3V I/O and is not compatible with 5V (connecting 5V signals directly may damage the board).

Powering the board from 5 V is possible by connecting a jumper at the bottom of the board and plugging in a USB cable. The Arduino Nano 33 BLE Sense also features a 6-pin debug connector (available as a test pad). Unlike other Arduino boards, the Arduino Nano 33 BLE Sense has an internal pull-up of the I2C line (pins A4 and A5) to the power line. The Arduino Nano 33 BLE Sense can be programmed via the Arduino IDE.

Features

  • BLE 5.0 U-Blox NINA B306 module with nRF52840 microcontroller (64 MHz, 1 MB Flash, 256 kB RAM)
  • IMU unit BMI270 and BMM150
  • Pressure sensor LPS22HB
  • HS3003 temperature and humidity sensor
  • Gesture sensor ADPS-9960
  • Digital microphone MP34DT06JTR
  • Micro USB socket
  • Voltage level 3.3 V
  • Number of I/O lines: 14 (6 can operate as PWM outputs)
  • GPIO, SPI, I2C, USART, PWM, ADC, DAC interfaces
  • 8 analogue inputs
  • Dimensions: 45 x 18 mm
1184056

Data sheet

Microcontroller
nRF52840
Core
Cortex M4
Frequency
64MHz
Flash memory
1024kB
RAM
256kB
EEPROM memory
none
Number of digital pins
14
Number of PWM channels
14
Ilość wejść analogowych
8
ADC
1x 12bit
DAC
none
CAN
none
USB
1
Ethernet
none
WiFi/BT module
No
Bluetooth module
Yes
GSM/GPRS module
No
Logic voltage
3,3 V
MicroSD slot
No
Supply voltage min
5 V
Supply voltages max
21 V
