Soldered Qwiic Adapter - I2C to Qwiic adapter
ID: 1208240
zł4.49
Tax included
zł3.65 tax excl.
Adapter designed for connecting conventional I2C modules to the Qwiic bus. It provides 2 Qwiic connectors and through-hole connections for SCL, SDA, 3.3 V, and GND, allowing modules without a native Qwiic connector to be integrated into a Qwiic system. Soldered 333015
Description
Two Qwiic connectors allow an I2C module to be integrated into a Qwiic system using standard Qwiic cables, while four plated through-holes provide access to the SCL, SDA, 3.3 V, and GND lines. The included pins can be soldered to the board, simplifying connections to existing modules or custom prototype circuits.
The operating voltage is 3.3 V, so the adapter should be used with circuits operating at the appropriate voltage level. The 2.54 mm pin pitch allows installation on a breadboard, while the mounting holes are compatible with LEGO spacing. The board measures 22 x 11 mm.
Features
- Type: I2C to Qwiic adapter
- Communication interface: I2C
- Number of Qwiic connectors: 2
- Connections: SCL, SDA, 3.3 V, GND
- Operating voltage: 3.3 V
- Pin pitch: 2.54 mm
- Breadboard-compatible design
- LEGO-compatible mounting holes
- Dimensions: 22 x 11 mm
- Open-source design
- Manufactured in Croatia, EU
Kit includes
- Soldered Qwiic Adapter - 1 pc.
- Pin header - 1 pc.
