Audio amplifier TPA7377 10W+10W+20W 12V-18V
ID: 587873
5906623464838
zł43.21
Tax included
zł35.13 tax excl.
Audio amplifier module with three output channels. It can be powered with the voltage from 12 to 18 V and has two outputs with a power of 10 W (left and right) and one with a power of 20 W (bass)
Description
Class AB audio amplifier module based on the TPA7377 chip. It has two channels with a power of 10 W (left and right) and one 20 W (bass) and is equipped with an active low-pass filter based on the NE5532 system. The module is supplied with the voltage in the range from 12 to 18 V. On a separate board there are 3 potentiometers for adjusting the gain level, low tones and the cut-off frequency. Two modules are connected by a tape - this solution facilitates the installation of the potentiometers in the housing. The audio input can be connected via an RCA connector or a 3-pin connector, while the outputs are led out on screw connectors. It works well as an element of a home audio system.
Features
- Power supply: terminal block
- Audio input: RCA socket or 3-pin audio connector
- Potentiometer for adjusting the bass volume
- Potentiometer to adjust the volume of the left and right channels
- Potentiometer to adjust the cut-off frequency
- Built-in rectifier bridge (Greatz)
- Operating voltage range: DC 12 to 18V
- Power: up to 10 W (left and right channel), 20 W (bass channel)
- Dimensions: 76 x 58 mm
Kit contains
- TPA7377 3-channel audio amplifier
- Module with potentiometers
- Wire
587873
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
