Bipolar stepper motor driver with TMC2208

Description

The advanced stepper motor controller based on the TMC2208 integrated circuit from Trinamic is an irreplaceable tool in the world of precision automation and robotics. This powerful module allows you to control and control stepper motors extremely precisely and effectively.

One of the key features of this controller is its versatility. Thanks to its compatibility with supply voltages from 4 V to 35 V, it can be successfully used with various types of stepper motors, including those with higher torque and higher supply voltages. This means that you have complete freedom in choosing the engine for your project. The TMC2208 controller uses advanced technologies, such as StealthChop2, which ensure not only quiet, but also extremely smooth operation of stepper motors. Thanks to SpreadCycle mode, it is possible to achieve higher speeds and torques, which is crucial in dynamic applications. Built-in protections, including an overheating protection mechanism, guarantee not only safety but also operational reliability. Additionally, the heat sink placed on the module effectively dissipates heat, which positively affects the performance and life of the controller.

The controller communicates via the STEP/DIR interface, which facilitates its integration with various devices and systems. It is also worth noting that it is compatible with most popular 3D printer control boards, making it an ideal choice for 3D printing enthusiasts. Despite its advanced capabilities, the controller is small in size, which makes it easy to install even in limited spaces. This is a solution that gives you full control over the stepper motors in your project, while ensuring reliability and efficiency of operation.

Features

• Integrated circuit: TMC2208 from Trinamic
• Motor supply voltage: 4 to 35 V
• Maximum continuous output current: 1 A
• Maximum instantaneous output current: up to 2 A
• Operating modes: StealthChop2, SpreadCycle
• Communication interface: STEP/DIR
• Configurable via UART & OTP interface
• Step division: up to 1/256
• Connectors: compatible with popular sockets
• Protections: overload, overheating and short circuits
• Dimensions: 20.3 x 15.2 mm
