1.02" monochrome E-Ink e-Paper display 128x80 - Waveshare 17574
ID: 582610
zł32.71
Tax included
zł26.59 tax excl.
Black and white e-Paper display with a diagonal of 1.02" and a resolution of 128x80 pixels. SPI interface. No PCB. Waveshare 1.02inch e-Paper
Description
Black and white e-Paper display with a diagonal of 1.02" and a resolution of 128x80 px. It has the ability to display content with a two-level gray scale and partial refresh function, and the built-in controller communicates via the SPI interface. E-Paper displays are characterized by high contrast of the displayed image and consume electricity only when the displayed content is changed It is compatible with 3.3V systems. Support is available on the product page in the form of examples of use with Raspberry Pi, Jetson Nano, Arduino and STM32.
Features
- Diagonal: 1.02"
- Resolution: 128x80 px
- Display color: black, white
- Gray levels: 2
- Interface: 3-wire SPI, 4-wire SPI
- Pixel size: 0.175 x 0.17
- Full refresh time: 2 s
- Partial refresh: 0.3 seconds
- Power consumption: 26.4 mW
- Viewing angle:> 170 °
- No backlight, display the last content after power off
- Low energy consumption
- Working voltage: 3.3V
- Display size: 21.76 x 14 mm
- Outline dimension: 32.6 x 18.6 mm
582610
Data sheet
- Screen type
- E-Ink/Epaper
- Diagonal (inch)
- 1,02
- Resolution
- 128 x 80 px
- Interface
- SPI
- Touch
- No
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
