- New
Axial fan 12V DC, 50x50x15mm, 31.43 m³/h, 38.1 dBA – Sunon MF50151VX-1000U-A99
ID: 1194618
zł12.90
Tax included
zł10.49 tax excl.
The Sunon MF50151VX-1000U-A99 fan is an efficient and compact cooling solution for electronic and industrial applications where reliable air circulation is required. It measures 50 x 50 x 15 mm, is powered by 12 V DC, reaches a rotation speed of 7200 RPM, provides an airflow of 31.43 m³/h at a noise level of 38.1 dBA. Sunon MF50151VX-1000U-A99
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Axial fan Sunon MF50151VX-1000U-A99 with dimensions of 50 x 50 x 15 mm designed to force air flow in electronic and industrial systems. Powered by 12 V DC, it operates in a wide voltage range from 4.5 V to 13.8 V DC. It provides high air flow efficiency at the level of 31.43 m³/h at a rotational speed of 7200 rpm and static pressure of 7.87 mm H₂O. Equipped with a brushless DC motor with an auto restart function, Vapo bearing and a housing and impeller made of durable thermoplastic. It is characterized by low power consumption of 1.32 W and a noise level of 38.1 dBA. The fan is used in devices requiring effective cooling with limited installation space, including electronic equipment, automation and embedded systems.
Features
- Fan type: DC
- Fan type: axial
- Operating voltage: 4.5...13.8 V DC
- Supply voltage: 12 V DC
- Rated current: 0.11 A
- Power consumption: 1.32 W
- Efficiency: 31.43 m³/h
- Rotation speed: 7200 rpm
- Static pressure: 7.87 mm H₂O
- Noise level: 38.1 dBA
- Bearing type: Vapo
- Housing material: thermoplastic
- Rotor material: thermoplastic
- Insulation class: A
- Min. insulation resistance: 10 MΩ
- Cable length: 0.3 m
- Cable size: 26 AWG
- Leads: cable x2
- Operating temperature: -10...70°C
- Flammability class: UL94V-0, ECE R-118
- Motor: brushless DC
- Additional functions: autorestart
- Gross weight: 29.82 g
1194618
Data sheet
- Voltage
- 4,5 - 13,8 V
- Rated current
- 110 mA
- Fan type
- Axial
