- New
Sunon MF50152VX-1000U-A99 - Axial fan 50×50×15 mm 24 V DC
ID: 1198417
zł21.38
Tax included
zł17.38 tax excl.
The Sunon MF50152VX-1000U-A99 axial fan, 50 × 50 × 15 mm, powered by 24 V DC, provides efficient ventilation with low energy consumption. Designed for use in cooling systems for electronic and industrial components.
Description
A compact axial fan designed for cooling electronic components and device enclosures. It operates in a wide supply voltage range from 8 V to 27.6 V DC, with optimal performance at the nominal voltage of 24 V DC. It provides an airflow of 31.43 m³/h at a rotational speed of 7200 rpm and a noise level of 38.1 dBA. Thanks to the use of a brushless DC motor with an auto-restart function and Vapo bearings, the fan is characterized by high reliability and long service life. The housing and impeller made of thermoplastic ensure resistance to mechanical and thermal factors. Designed to operate at temperatures from -10°C to 70°C, with UL94V-0 flammability rating. Equipped with power wires of 0.3 m length and 26 AWG gauge.
Properties
- Fan type: DC, axial
- Dimensions: 50 × 50 × 15 mm
- Operating voltage: 8...27.6 V DC
- Supply voltage: 24 V DC
- Power consumption: 1.4 W
- Rated current: 55 mA
- Airflow: 31.43 m³/h
- Static pressure: 7.87 mm H₂O
- Noise level: 38.1 dBA
- Rotational speed: 7200 rpm
- Bearing type: Vapo
- Motor: brushless DC
- Additional functions: auto-restart
- Operating temperature: -10...70°C
- Flammability class: UL94V-0
- Housing material: thermoplastic
- Impeller material: thermoplastic
- Leads: 2 × 0.3 m wires (26 AWG)
- Insulation resistance: min. 10 MΩ
- Gross weight: 30.56 g
1198417
Data sheet
- Voltage
- 8 - 27,6 V
- Power
- 1,4 W
- Length
- 50mm
- Width
- 50 mm
- Height
- 15 mm
- Weight
- 30,56 g
- Noise level
- 38,1 dBA
- Air flow efficiency
- 31,43 m³/h
- Rated current
- 55 mA
- Fan type
- Axial
