Stabilized laboratory power supply with programmable memory and stepless voltage regulation from 0 to 35 V and stepless current regulation from 0 to 6 A. It has a built-in USB Type A connector with Quick Charge function. Hantek HDP135V6A

24h
Available
Available quantity: 5
Kamami is the official distributor of Hantek oscilloscopes and accessories. All products of this brand in our offer are original and come directly from the manufacturer.


Free shipping

free shipping in Poland for all orders over 500 PLN



Same day shipping

If your payment will be credited to our account by 11:00



14 days for return

Each consumer can return the purchased goods within 14 days

Description

The HDP135V6A laboratory power supply is a stabilized power supply with programmable memory and stepless voltage regulation from 0 to 35 V and stepless current regulation from 0 to 6 A. It has overvoltage, overcurrent, overload, overheating and short-circuit protection functions. Built-in memory allows it to store 10 groups of functions. It offers USB fast charging functions with 5-12V output and support for various fast charging protocols.  The power supply can operate C.V. modes. - Constant output voltage and C.C. constant load current.

The HDP135V6A is cooled by a fan that runs non-stop and its speed depends on the load. The power supply is distinguished by large high-precision LED displays that keep you informed of the current voltage and load with an accuracy of 10 mV and 1 mA.

Set the voltage as well as the current in a very convenient way using the position selection buttons to change and the potentiometer. This is an ideal power supply for the laboratory, production line and maintenance of home appliances.

Features

  • Precision extended power supply with memory
  • Easy-to-read digital LED displays
  • Built-in fan
  • Short circuit and overload protection
  • High accuracy and measurement resolution of 10mV / 1mA
  • Low noise level
  • Operation in CV mode (voltage mode) or CC mode (output current mode)
  • High reliability and speed of operation high current protection (OCP) and over voltage output protection (OVP)
  • Memory buttons, 10 different power supply settings can be programmed
  • Voltage range: 0 to 35 V
  • Current range: 0 to 6 A
  • Load adjustment
    • Voltage: =< 0.01% +5 mV
    • Current: =<0.2% +3 mA
  • Parameter setting accuracy
    • Voltage: 10 mV
    • Current: 1 mA
  • Output voltage ripple
    • Voltage: =< 10 mVrms
    • Current: =< 5 mArms
  • Response time
    • Voltage rise time: =< 100mS (Rated load 10%)
    • Voltage drop: =< 100mS (Rated load 10%)
  • Overvoltage protection (OVP): 0 to 35V ± 0.2%FS
  • Overcurrent protection (OCP): 0 to 6A ± 0.2%FS
  • USB type A output with Quick Charge function from 5V to 12V, 18W
  • Dimensions: 85 x 160 x 260 mm
  • Weight: 2 kg

Kit contains

  • Laboratory power supply HDP135V6A
  • Crocodile type cables
  • Power supply cable
1183728

Data sheet

Output voltage
0 - 35 V
Output current
6A
Number of channels
1
