LILYGO TTGO Meshtastic T-Beam V1.2 - Development Board with ESP32 Module, LoRa 868MHz Communication and OLED Display
ID: 1196426
5902186303416
zł217.51
Tax included
zł176.84 tax excl.
Advanced ESP32-based communication module with Wi-Fi and Bluetooth 4.2 support, equipped with LoRa SX1276 chip for long-range transmission in the 868 MHz band. Integrated NEO-6M GPS module and 0.96" OLED display enable real-time location and data viewing, and built-in 18650 cell cage provides mobility and energy independence. T-Beam V1.2 is ideal for projects based on mesh networks, providing reliable connectivity in field and IoT applications. LILYGO TTGO Meshtastic T-Beam V1.2
Description
LILYGO TTGO Meshtastic T-Beam V1.2 is a modern communication module based on Mesh network technology, operating in the 868 MHz band. The device is equipped with an ESP32 microcontroller that supports both Wi-Fi and Bluetooth 4.2, making it highly versatile for IoT projects. The integrated LoRa SX1276 module enables long-range wireless communication, even in challenging terrain. Additionally, the built-in NEO-6M GPS module provides real-time geolocation, making the board ideal for navigation and tracking applications. It also features a 0.96" OLED display for convenient monitoring of operational parameters. Thanks to the 18650 battery holder, the module can operate completely off-grid, further enhancing its usability. TTGO T-Beam V1.2 is perfect for building Mesh networks where each node can forward signals, creating a reliable long-range communication system.
Features
- Microcontroller: ESP32
- Flash memory: 4MB
- PSRAM: 8MB
- Wireless connectivity: Wi-Fi + Bluetooth 4.2
- GPS module: NEO-6M
- LoRa module: SX1276 (868 MHz)
- Supports the Meshtastic protocol
- Supports the MeshCore protocol in the following modes:
- Companion
- Repeater
- Room Server
- UART converter: CH9102F
- Power management controller: AXP2101
- Display: OLED 0.96" (SSD1306)
- Connector: microUSB (for power and programming)
- Battery support: 18650 battery holder
- Built-in antennas: LoRa, GPS, 3D Wi-Fi
- Buttons: Power, Reset, IO38
- Dimensions: 100 x 33 x 25 mm
Kit contains
- T-Beam board with pre-soldered OLED display
- 868 MHz LoRa antenna
- 2 × goldpin headers
1196426
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
You might also like
Cable with USB typ A and microUSB typ B connectors, cable length 1 m. LANBERG CCP-MUSB2-AMBM-W-1M
zł2.96
24h
Available quantity: 40
Available
Cable with USB type A and microUSB type B plugs, length 2m, white
zł6.83
Delivery date unknown
No product available!
Other products in the same category (16)
The module with the SX127x 433 MHz system for LoRa communication, designed for FireBeetle boards. It communicates via the SPI interface. DFRobot TEL0121
zł93.69
4 weeks
No product available!
Radio module with operating frequency of 433 MHz. Communication takes place via the UART serial interface. It is supplied with the voltage in the range from 3.3 to 5 V. DFRobot TEL0114
zł225.78
24h
Available quantity: 1
Available
LoRa MESH Radio Module is a radio module with an operating frequency of 868MHz. Communication with the module takes place via the UART serial interface. It has a range up to 3km. It is supplied with voltage in the range of 3.3-5V. DFRobot TEL0117
