This module allows independent control of two Omron G5LE-14-DC12 SPDT relays, supporting currents up to 10A. Thanks to built-in BSS138K MOSFETs, it can be controlled directly from 3.3V or 5V development boards such as Arduino or Raspberry Pi. Each channel is equipped with an LED to indicate relay activation and 5mm screw terminals for convenient circuit connection. Pololu 5666

24h
Available
Available quantity: 1
Kamami is the official distributor of electronic modules and Pololu robotic parts. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Basic 2-Channel SPDT Relay Carrier is a module that allows easy and independent control of two SPDT (Single Pole Double Throw) relays using low-voltage and low-current control signals. The board is equipped with two Omron G5LE-14-DC12 relays, capable of switching currents up to 10 A in most applications. Thanks to the integrated BSS138K MOSFET transistors, the module can be easily controlled by logic signals from Arduino, Raspberry Pi, or other 5 V / 3.3 V systems. Each channel features an LED indicator showing relay activation, making diagnostics and testing more convenient.

The module includes a 4-pin JST SH connector compatible with Pololu, SparkFun Qwiic, and Adafruit STEMMA QT cables (note: the interface is not I²C-compatible). The relay switching contacts (NO, NC, COM) are accessible through 5 mm pitch screw terminals, making integration with external circuits easy. The built-in Zener diode ensures rapid coil current decay, extending relay lifespan. The board features a compact layout and carefully designed trace spacing with minimum isolation distances for safe and stable operation.

The board has four mounting holes suitable for M3 or #4 screws, allowing secure installation in various projects. The manufacturer also offers optional relay power input through a DC power jack (to be installed by the user). Overall, this module is a complete solution for controlling high-power devices such as motors, lighting, pumps, and solenoid valves.

Features

  • Number of channels: 2
  • Relay coil voltage: 12 V DC
  • Relay type: Omron G5LE-14-DC12
  • Maximum switching current: 10 A
  • Coil activation current: approx. 80 mA
  • Control connector: 4-pin JST SH (VDD, GND, EN1, EN2)
  • Output connectors: 3-pin terminal blocks (NO, NC, COM), 5 mm pitch
  • Control transistors: BSS138K N-MOSFET
  • Zener diode: fast coil current discharge
  • LED indicators: red LEDs for each relay
  • Control voltage: logic signal 2.5–20 V DC
  • Mounting holes: 4 × M3 / #4
  • Dimensions: 46 × 38 × 23 mm
  • Weight: 34 g
1201584

Data sheet

Output current
10A
Number of channels
2
Executive element
Przekaźnik
Coil voltage
12 VDC
