1-channel SSR relay module 240V/2A triggered by high state
ID: 1184409
5906623447381
zł6.70
Tax included
zł5.45 tax excl.
Module with one 240V/2A relay controlled by 5V with a fuse triggered by a high state. modSSR-1CH-H
Description
Module with one SSR relay 75-264 V AC with a load of up to 2 A, triggered by a high state. It allows you to switch high-power devices using, for example, a microcontroller. The relays are operated with a voltage of 5 V. Compared to electromechanical relays, SSRs are based on semiconductor elements (transistors and thyristors) and offer a higher switching speed. The relays used in the module can only control alternating current.
Features
- One SSR relay
- Control signal input voltage:
- 0-0.5V SSR - OFF
- 2.5-20V SSR - ON
- Load voltage range: 75 to 264 VAC (50/60 Hz)
- Load current: 0.1 to 2 A
- Supply voltage: 5V (160mA)
1184409
Data sheet
- Output current
- 2A
- Number of channels
- 1
- Executive element
- SSR
- Coil voltage
- Nie dotyczy
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
