PT6LV 100k - Horizontal mounting potentiometer
ID: 30678
zł1.38
Tax included
zł1.12 tax excl.
The PT6LV 100k potentiometer, with a carbon resistance element and a dustproof housing, provides precise resistance control for advanced electronics. It offers a variety of mounting and adjustment options, stock availability for automatic installation, and extended-life and clamp-free models.
Description
The PT6LV 100k potentiometer is a precise device with a resistance element made of carbon, enclosed in a dustproof housing. Thanks to its polyester substrate and a variety of mounting and adjustment options, it is ideal for applications in electronic systems requiring precise resistance control. Can be supplied in magazines for easy automatic installation. Long-life models and versions without clamps are also available
Properties
- Value range: 100 kΩ
- Stopping torque: > 4 Ncm (> 5.6 in-oz)
- Torque: 0.2 to 2 Ncm (0.3 to 2.7 in-oz)
- Electric rotation angle: 200° ± 20°
- Mechanical rotation angle: 235° ± 5°
- Maximum voltage: 100 VDC (linear), 50 VDC (non-linear)
- Rated power at 50°C: 0.1 W (linear), 0.05 W (non-linear)
- Operating temperature: -25°C to +70°C (-13°F to +158°F)
- Mechanical life: 500 cycles
- Tolerance: ±20%
30678
