  • Moduł z czujnikiem odbiciowym QTRX-MD-01A
  • Moduł z czujnikiem odbiciowym QTRX-MD-01A (widok z góry i dołu)
  • QTRX-MD-01A - module with 1 reflectance sensor with analog output
ID: 572603
5906623479061
zł18.14
Tax included

zł14.75 tax excl.

Module with 1 QTRX type optocoupler with analog output. The module operates from 2.9 V to 5.5 V, detects objects at a distance of up to 30 mm. The sensor will be used in projects that require detection of changes in the ground, e.g. in linefollower robots. Pololu 4441

24h
Available
Available quantity: 3
Kamami is the official distributor of electronic modules and Pololu robotic parts. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Reflectance sensor consisting 1 QTRX optocoupler with the ability to individually control the brightness of the infrared LEDs. The sensors on the board are medium density (MD) and the distance between them is 8 mm. The module can be supplied with the voltage ranging from 2.9 V to 5.5 V and draws current up to 5 mA. The optimum distance from the sensor to the ground is 10 mm and the maximum distance is 30 mm. The module is ideally suited for detecting changes in light reflection, so it can be used for edge detection or line tracking in linefollower robots.

Features

  • Sensor type: QTRX
  • Number of sensors:1
  • Sensor pitch: 8 mm (distance between individual sensors)
  • Full brightness LED current: 3,5 mA (regardless of the supply voltage)
  • Maximum module current: 5 mA
  • Output signal: analog signal (0 V to VCC)
  • Optimum sensing distance: 5 mm
  • Maximum sensing distance: 30 mm
  • Supply voltage: 2.9 ... 5.5 V
  • Dimensions: 7,5 × 20,0 × 3,0 mm
  • Weight: 0,35 g
572603

Data sheet

Type of sensor
QTRX
Output type
analog
Number of sensors
1
Power supply voltage
2,9 - 5,5 V
