AVT5340 C

More and more computer systems cooperate with the Ethernet digital network. Some of them have special communication interfaces built in, usually designed for handling specialized peripherals. As a rule, this is associated with their considerable cost. We offer an alternative - cheap and easy to perform Ethernet / UART converter. For most amateur applications, its parameters are quite sufficient. A series of inputs and outputs makes it easy to use in very different applications.

The device is particularly recommended as an element of systems cooperating with the Internet

Selected parameters:

• bi-directional UART to Ethernet conversion
• 6 digital inputs / outputs (with the possibility of increasing to 11)
• two analog inputs (10 bit resolution)
• PWM output, two interrupt inputs
• configuration and management via a website
• UDP controlled
• operation status indication - LED diodes
• power supply - 3.3Vdc
• system assembled and running

  Detailed description in
  EP4 / 12
  or
