X-NUCLEO-53L1A2 - expansion board with distance sensor VL53L1 for STM32 Nucleo
ID: 581301
5906623410651
zł202.48
Tax included
zł164.62 tax excl.
Extension board with distance sensor ToF VL53L1, The sensor has a range of up to 400 cm. The kit includes 2 modules with sensors that can be connected via a 10-pin connector. The shield is compatible with STM32 Nucleo boards and has an Arduino UNO R3 connector. STMicroelectronics X-NUCLEO-53L1A2
Description
X-NUCLEO-53L1A2 is an expansion board with a ToF VL53L1 distance sensor designed for STM32 Nucleo sets, the Sensor has a long range (up to 400 cm). The kit includes 2 modules with sensors that can be connected via a 10-pin connector. The shield is compatible with STM32 Nucleo boards and has an Arduino UNO R3 connector. The expansion board can work with the NUCLEO-F401RE and NUCLEO-L476RG kits.
Features
- VL53L1 Time-of-Flight ranging sensor with multi object detection and field of view (FoV) programming
- Accurate absolute ranging distance measurement, independent of the reflectance of the target
- 0.25, 0.5 and 1 mm spacers to simulate air gaps between ToF sensor and cover window
- Two different cover windows
- Two VL53L1 breakout boards which can be connected onto the X-NUCLEO-53L1A2 expansion board through flying wires to integrate the VL53L1 into the customer’s application
- Compatible with STM32 Nucleo board family
- Equipped with Arduino™ UNO R3 connector
- Full system software (SW) is supplied, including code examples and graphical user interface. All this can be downloaded from the folder “Tools & Software", section "Embedded software" on the product page
Kit contains
- X-NUCLEO-53L1A2 expansion board
- 2 x Module with sensor VL53L1
- A set of air gaps
581301
Data sheet
- Interface
- I2C
- Type of sensor
- ToF
- Minimum distance
- 4 cm
- Maximum distance
- 400 cm
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
