STM32L4R9I-EVAL - development kit with STM32L4R9AI microcontroller
search
  • STM32L4R9I-EVAL - development kit with STM32L4R9AI microcontroller
ID: 568401
zł1,722.00
Tax included

zł1,400.00 tax excl.

The STM32L4R9I-EVAL evaluation set was designed to demonstrate the capabilities of the STM32L4R9AI microcontroller. Mounted connectors allow easy connection of extensions. The board also has a debugger / ST-LINK / V2-1 programmer. STM32L4R9I-EVAL

1 weeks
On request

Description

The STM32L4R9I-EVAL Evaluation Kit was designed to demonstrate the capabilities of the STM32L4R9AI microcontroller based on the ARM ® Cortex ® -M4 core. The microcontroller is equipped with 4 I 2 C ports, three SPI and six USART, CAN port, two SAI ports, 12-bit ADC converter, 12-bit DAC converter, built-in 640 KB SRAM memory, FLASH memory with 2 MB capacity, two Octo-SPI interfaces, USB OTG FS port, LCD-TFT controller, MIPI DSI host, FMC controller, 8 ... 14-bit camera interface and support for debugging with JTAG.

The board offers the possibility of testing and development of applications using a large number of peripherals (USB, USART, digital microphones, ADC and DAC converters, TFT LCD, MIPI DSI LCD, LDR, SRAM, NOR Flash memory, Octo-SPI Flash memory, microSD card, modulators sigma-delta, CAN transceiver, EEPROM). Mounted connectors allow easy attachment of extensions.

The board also has a built-in debugger / ST-LINK / V2-1 programmer, which can also be used as a virtual COM port.

properties

  • STM32L4R9AII6 microcontroller with a built-in Flash memory with a capacity of 2 MB and RAM memory with a capacity of 640 kB; UFBGA169 housing
  • MIPS DSI 1.2 "390x390 round LCD screen
  • 4.3 "480x272 TFT LCD screen with RGB mode
  • Two ST-MEMS digital microphones
  • 8 GB microSD card included
  • SRAM memory with a capacity of 16 MBit
  • NOR Flash 128 MB memory
  • Octo-SPI Flash memory with 512 MBit capacity with DTR support
  • Octo-SPI SRAM memory with a capacity of 64 MBit with HyperBus interface support
  • EEPROM memory supporting I 2 C 1 MHz communication
  • Reset and wakeup buttons
  • 4-way joystick with selector
  • Touch button
  • photoresistor
  • Potentiometer
  • CR1220 battery for providing backup power
  • Connectors on the board:
    • Two 3.5 "Jack Audio Outputs
    • MicroSD card slot
    • Standard TFT LCD connector
    • Standard MIPI DSI LCD connector
    • EXT_I2C connector supporting the I 2 C bus
    • RS-232 - communication or MCU programming option
    • USB OTG FS Micro-AB
    • CAN 2.0A / B
    • Connection with the input to the ADC converter and output from the DAC converter
    • JTAG / SWD
    • ETM
    • Virtual COM port via USB
    • TAG connector for ST-LINK / V2-1
    • STDC14
    • PMODE
  • Flexible PCB power supply: DC, ST-LINK / V2-1 USB or USB OTG connector
  • Built-in debugger / ST-LINK / V2-1 programmer, which can also be used as a virtual COM port or mass storage.
  • Microcontroller power supply: 3.3 V constant or adjustable from 1.71 ... 3.6 V
  • Circuit measuring the current consumed by the microcontroller
  • Access to the comparator and operational amplifier built into STM32L4R9AII6
  • Full compatibility with versatile HAL libraries containing many examples of the use of microcontroller peripherals and STMicroelectronics
  • Supported a wide range of development software such as IAR, Keil and GCC-based environments
