SuperPro 610P - universal programmer with USB interface

Description

Universal programmer for EEPROM, PROM, NVRAM, SPLD, CPLD, EPLD and MCU units. The device is controlled from a Windows computer using a dedicated application, and communication takes place via the USB 2.0 interface. The programmer is equipped with a ZIF-48 socket and with the use of additional adapters it can program circuits in various types of housings, including DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP , SON, CSP, SCSP and various voltage levels from 1.2 V to 5 V. The programmer offers numerous functions that facilitate work with the device, including production mode, generation of serial numbers or data logging during operation. The wide range of supported systems (the full list includes 247 manufacturers and over 34,000 devices) makes the Superpro 610P suitable for both professional and hobby applications.

Features

• Supports integrated circuits from 247 manufacturers (over 34,076 chips)
• Supports devices with Vcc from 1.2V to 5V
• ZIF-48 socket
• PC mode and standalone mode
• Programming algorithms approved by the IC manufacturer
• Advanced and extensive functions:
  • The production mode starts the chip operation when the chip is correctly inserted into the socket
  • Design function simplifies processes such as device selection, file loading, device configuration setting, program option and batch file setting in one step
  • You can set a password for project files and production volume control
  • A batch command combines device operations such as programming, verification, security into one command in any sequence
  • Serial number generators
  • Quality tracking data logging
• Overcurrent and overvoltage protection
• Compatibility with Windows XP, Vista, Win7, Win10

Kit contains

• Xeltek SuperPro 610P programmer
• Power Supply
• USB 2.0 cable
• Software CD
