DFRobot Gravity Digital I2C multiplexer
ID: 572470
5906623405916
zł33.73
Tax included
zł27.42 tax excl.
I2C multiplexer module with TCA9548A system. Allows you to connect up to 8 devices. The system works like a gateway - it transmits I2C interface data to one of the 8 main busses. This allows you to connect up to 8 devices with the same address. DFRobot DFR0576
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
Gravity: Digital 1-to-8 I2C Multiplexer is an I2C multiplexer module with TCA9548A chip. Allows you to connect up to 8 devices. The system works like a gateway - it transmits I2C interface data to one of the 8 main busses. This allows you to connect up to 8 devices with the same address. The multiplexer address can be set using the jumpers on the back of the module (0x70 by default). Thanks to this, you can join up to 8 multiplexers with different addresses, and thus up to 64 I2C address spaces.
properties
- Number of I2C ports: 8
- Default I2C address: 0x70
- I2C address range: 0x70-0x77
- Interface protocol: I2C (IIC)
- I2C Clock Rate: 100K, 400K
- Connector type: GravityPH2.0-4P
- Operating voltage: 3.3-5 V
- Dimension: 32 x 32 mm
Included
- Gravity Module: Digital 1-to-8 I2C Multiplexer
- Cable UART / I2C Gravity 4pin
- XH2.54-5pin connector
572470
