Motoron M1U550 Single Serial Motor Controller - DC motor controller (for assembly)
ID: 1185698
5902186316850
zł59.86
Tax included
zł48.67 tax excl.
A single-channel DC motor controller with a UART TTL interface. It is powered from 1.8 V to 22 V and can deliver up to 1.8 A of current. Board with connectors for assembly. Pololu 5077
Description
A DC motor controller that allows the movement of a single drive to be controlled via a UART TTL interface. It can operate with motors with supply voltages from 1.8 to 22 V and has a capacity of up to 1.8 A (continuous operation). The controller has built-in protection in case of loss of communication with the main controller and a configurable response if an error occurs. The user can set the maximum acceleration and initial speed of the motor Using a single UART bus, it can control several modules. A user manual and a library with example programmes are available on the manufacturer's website.
Features
- Operating voltage range: 1.8 V to 22 V
- Maximum output current per motor: 1.8 A continuous, 5 A instantaneous
- Voltage range of the logic part: 3 V to 5.5 V
- Control interface: UART TTL, up to 250 kbps
- CRC control possible
- Configurable motion parameters:
- Maximum acceleration/deceleration
- Initial speed
- Delay for change of direction
- PWM frequency: eight options from 1 kHz to 80 kHz available
- Protection in case of communication loss
- Configurable automatic error response
- Measurement of motor supply voltage (VIN)
- Two status LEDs
- Motor direction LEDs
- Dimensions: 15.24 x 15.24 mm
Kit contains
- Motoron M1U550 Single Serial Motor Controller
- Connector 1x12 straight male
1185698
Data sheet
- Output current
- 1,8 A
- Number of channels
- 1
- Supply voltage min
- 1,8 V
- Supply voltages max
- 22 V
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
