Adafruit Feather HUZZAH with WiFi module ESP8266
ID: 560910
5906623429011
zł96.57
Tax included
zł78.51 tax excl.
Adafruit Feather HUZZAH ESP8266 is a new development board from Adafruit with a built-in WiFi module ESP8266. Processor frequency: 80 MHz, USB-serial TTL CP2104 converter, Li-Pol battery charger. Adafruit 2821
Descritpion
Adafruit Feather HUZZAH ESP8266 is a new development board from Adafruit with a built-in WiFi module ESP8266.
The heart of the board is the ESP8266 module with a microcontroller clocked at 80 MHz and logic working in the voltage range from 0 to 3.3 V. The programming of the board is extremely simple thanks to the Arduino IDE environment providing a quick start of projects related to IoT technology. On the board there is a USB converter module - Serial TTL, CP2104 providing the ability to quickly load the code and communications with a speed of 921600 baud.
On PCB used the connector of a single-purpose battery Li-Pol with voltage of 3,7V for easier use in portable applications. The built-in charging system ensures charging by connecting via a USB connector.
Features
- Based on ESP8266 system, 80 MHz
- 4MB FLASH memory
- Built-in WiFi module 802.11 b / g / n
- Built-in voltage regulator 3.3V, 500mA
- Built-in converter USB-serial TTL based on CP2104 USB phone
- The ability to transmit data from 921600 bps
- Autoreset function after uploading the firmware
- 9 GPIO pins,/li>
- 1 analog input
- Built-in Li-Pol charger with a charging current up to 100mA with LEDs for charging status indication
- Two diode for signaling the system operation
- Work volatage / logic: 3,3V
- Dismension: 51 x 23 x 8 mm
- Weight: 9,7g
560910
Data sheet
- Microcontroller
- ESP8266
- Flash memory
- 4 MB
- Number of I/O
- 09
- Ethernet
- none
- WiFi/BT module
- Yes
- Bluetooth module
- No
- MicroSD slot
- No
- Length
- 51mm
- Width
- 23 mm
- USB connector type
- microUSB type B
