Low-noise RF amplifier 100 kHz – 4 GHz ZK04-UM Zeenko UM Series, USB-C
ID: 1201358
zł55.93
Tax included
zł45.47 tax excl.
Zeenko ZK04-UM is a compact low-noise RF amplifier operating in the 100 kHz – 4 GHz range, powered via USB-C, featuring high linearity and low noise levels. Ideal for amplifying antenna signals or as a preamplifier for spectrum analyzers such as the tinySA ULTRA, especially above 3.5 GHz.
Description
The ZK04-UM is a wideband low-noise amplifier (LNA) powered via USB Type-C, part of the UM series from Zeenko. The device operates in the frequency range from 100 kHz to 4 GHz, offering moderate gain tailored to practical applications and a very low noise figure (NF). The high-PSRR LDO regulator effectively suppresses power-supply noise, resulting in better signal quality compared to standard USB-powered modules.
The module features a shielded system enclosure, a compact design, and the ability to adjust supply current by changing an external bias resistor. It is ideal as an antenna amplifier or a preamplifier for spectrum analyzers, enhancing sensitivity for devices such as the tinySA ULTRA.
Properties
- Frequency range: 100 kHz – 4 GHz
- Power supply: USB Type-C, 5 V
- Supply current: 26 mA (adjustable via bias resistor)
- Gain:
- 25 dB @ 100 kHz / 5 MHz
- 23 dB @ 10 MHz
- 21.5 dB @ 100 MHz
- 18 dB @ 1 GHz
- 14 dB @ 2 GHz
- 11 dB @ 3 GHz
- 9 dB @ 4 GHz
- Noise figure (NF):
- 2.3 dB @ 10 MHz
- 1 dB @ 100 MHz
- 0.7 dB @ 1 / 2 / 3 GHz
- 1 dB @ 4 GHz
- OP1dB (1 dB compression point):
- 13 dBm @ 10 MHz
- 16 dBm @ 100 MHz
- 17 dBm @ 1 / 2 GHz
- 18 dBm @ 3 GHz
- 17 dBm @ 4 GHz
- OIP3 (third-order intercept point):
- 22 dBm @ 10 MHz
- 27 dBm @ 100 MHz
- 26–28 dBm @ 1–4 GHz
- Power interface: USB-C
- Enclosure: shielded, compact
- Notes: low power, low noise, recommended moisture protection for outdoor use
- Compatibility: may replace SPF5189Z, SPF5043Z modules
