MP23ABS1TR analog microphone (MEMS)
ID: 1185198
5906623481590
zł7.87
Tax included
zł6.40 tax excl.
The MP23ABS1TR is a compact, low-power microphone featuring a capacitive sensor and IC interface. The sensing element, capable of detecting acoustic waves, is manufactured using a specialized silicon micromachining process to produce audio sensors
Description
The MP23ABS1TR is a compact, low-power microphone featuring a capacitive sensor and IC interface. The sensing element, capable of detecting acoustic waves, is manufactured using a specialized silicon micromachining process to produce audio sensors. The MP23ABS1 has an acoustic overload point of 130 dBSPL with a typical signal-to-noise ratio of 64 dB. The sensitivity of the MP23ABS1 is -38 dBV ±1 dB at 94 dBSPL, 1 kHz. The MP23ABS1 is available in a reflow compatible housing and is guaranteed to operate in an extended temperature range of -40°C to +85°C.
Features
- Type: MEMS (silicon)
- Output Type: Analog
- Direction: Omnidirectional
- Frequency range: 35Hz ~ 1.5kHz
- Sensitivity: -38dB ±1dB at 94dB SPL
- S/N ratio: 64dB
- Voltage - Rated: 2.75V
- Current: 150µA
- Port Location: Bottom
- Completion: Solder Pads
- Size/Dimension: 3.50mm x 2.65mm
- Height (max.): 1.08 mm
- Shape: Rectangular
1185198
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
