Portable digital oscilloscope with a 200 kHz bandwidth, 2.5 MS/s real-time sampling rate, 2.8" TFT LCD display with a resolution of 320 × 240 pixels, one-button AUTO function, built-in 1000 mAh battery, and an extended accessory set. FNIRSI DSO152 High Profile

24h
Available
Available quantity: 15
Kamami is the official distributor of Fnirsi measuring tools. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The FNIRSI DSO152 is a portable digital oscilloscope designed for basic analog and digital signal analysis. Its compact housing, lightweight construction, and built-in 1000 mAh rechargeable battery make it suitable for both bench work and field applications. With a 200 kHz bandwidth and a 2.5 MS/s real-time sampling rate, the oscilloscope is well suited for troubleshooting electronic circuits, maintenance tasks, educational use, and hobby electronics projects.

Clear display and intuitive operation

The oscilloscope features a 2.8-inch TFT LCD color display with a resolution of 320 × 240 pixels, providing a clear waveform view. The one-button AUTO function automatically adjusts the measurement parameters, allowing waveforms to be displayed without manual configuration. Auto, Normal, and Single trigger modes support the observation of both periodic analog signals and non-periodic digital signals. Holding the AUTO button performs a quick baseline calibration.

The device is operated using five dedicated function buttons located below the display and a four-way navigation pad with a central confirmation button, allowing convenient menu navigation and quick adjustment of measurement parameters.


The built-in 1000 mAh lithium battery provides up to approximately 4 hours of continuous operation on a full charge. The USB Type-C interface supports battery charging, firmware updates, and data transfer. FNIRSI provides the latest firmware versions and supporting documentation through its official website. The High Profile version includes all essential accessories required to begin measurements immediately after unpacking.

Features

  • 200 kHz bandwidth
  • 1 input channel
  • 2.5 MS/s real-time sampling rate
  • 4096-point memory depth
  • vertical sensitivity: 10 mV/div to 20 V/div
  • time base: 10 μs/div to 50 s/div
  • input voltage range with X1 probe: ±40 V (80 Vpp)
  • input voltage range with X10 probe: ±400 V (800 Vpp)
  • input impedance: >1 MΩ
  • AC and DC input coupling
  • Auto, Normal, and Single trigger modes
  • one-button AUTO configuration
  • 1 kHz square-wave calibration output, 50% duty cycle
  • 2.8-inch TFT LCD display
  • display resolution: 320 × 240 pixels
  • USB Type-C interface
  • built-in 1000 mAh lithium battery
  • battery life: up to 4 hours
  • charging: 5 V / 1 A
  • dimensions: 99 × 68.3 × 19.5 mm
  • weight: approximately 100 g

Kit includes

  • FNIRSI DSO152 digital oscilloscope
  • BNC oscilloscope probe
  • MCX to BNC adapter
  • test lead
  • USB Type-C cable
  • user manual
1185660

Data sheet

Type of oscilloscope
Digital
Bandwidth
200 kHz
Sampling rate
2,5 MS/s
Memory depth
Inny
Number of channels
1
