zł380.31 tax excl.
The camera module is based on a CMOS sensor - AR0134. It has a resolution of 1280 x 960 px (1.2 MPx). The module supports recording of video sequences: 1280 x 960 @ 54fps and 1280 x 720 @ 60Ffps. Intended for use only with the ArduCam USB Shield module. Arducam B0100
Free shipping
free shipping in Poland for all orders over 500 PLN
Same day shipping
If your payment will be credited to our account by 11:00
14 days for return
Each consumer can return the purchased goods within 14 days
Description
The camera module is based on a CMOS sensor - AR0134. It has a resolution of 1280 x 960 px (1.2 MPx). The module supports recording of video sequences: 1280 x 960 @ 54fps and 1280 x 720 @ 60Ffps. It is equipped with an LS-6020 lens with a focal length of 6 mm, a viewing angle of 60 °, a F2.2 shutter and a 1/3 "format.
Camera module for use only with the ArduCam USB Shield module.
properties
- Intended for use with the ArduCam USB Shield module
- Matrix: AR0134 (CMOS)
- Resolution: 1280 x 960 px (1.2 MPx)
- Snapshot type: Global Shutter
- Video recording:
- 1280 x 960 pixels @ 54 FPS
- 1280 x 720 pixels @ 60 FPS
- Pixel size: 6.0 x 6.0 um
- Sensitivity: 5.3V / lux-sec
- Parallel interface
- The LS-6020 lens
- Focal length: 6 mm
- Aperture: F2,2
- Viewing angle: 60 °
- Format: 1/3 ''
- Mounting M12
- Power supply: 3.3 V
- Four mounting holes
- Camera module dimensions: 40 x 40 mm
Data sheet
- Resolution
- 1.2MPx
- Interface
- Parallel
- Sensor
- AR0134
- IR filter
- Yes
- Lens assembly
- M12x0.5
