Raspberry Pi Global Shutter Camera
ID: 1183995
5056561803234
zł269.00
Tax included
zł218.70 tax excl.
Camera with a global shutter designed for Raspberry Pi minicomputers. Works with all versions of minicomputers with a CSI slot. The camera is equipped with a Sony IMX296 sensor with a resolution of 1.5 MPx and a built-in IR filter. Raspberry Pi Global Shutter Camera
Description
Raspberry Pi Global Shutter Camera is the new official camera for Raspberry Pi minicomputers. Track with version tracking for minicomputers that have a CSI socket. The camera is equipped with a Sony IMX296 sensor with a resolution of 1.5 MPx and an IR filter.
The camera has the option of mounting lenses with CS (6 mm) and C (16 mm) mounts. The kit also includes a C-CS adapter for mounting lenses of both types. The camera has two official lenses: 16 mm telephoto lens and 6 mm wide-angle lens.
Attention!
The kit does not include camera lenses. They must be bought separately.The Raspberry Pi Global Shutter Camera is a great tool for a mobile app moving around your facility very quickly. The special feature of this camera is a global shutter that allows you to read data from all pixels, which is an advantage over rolling shutter mechanisms that transmit the image starting at the upper pixels and ending at the lower ones. Due to the moving shutter recording, the recording of moving objects is blurry, therefore it is because by the time the camera reads the data from the lower pixels of the object, it has already moved. The use of a global snapshot that reads all ten-issue evaluation pixels at a time. The camera will be used in sports photography and machine vision systems.
Features
- Compatible with Raspberry Pi version drivers (Raspberry Pi 4 model B, Raspberry Pi 3 model B+, Raspberry Pi 3 model B, etc.)
- Sony IMX296 sensor
- Resolution 1.58 MP
- Viewer diagonal 6.3mm
- Pixel size 3.45μm × 3.45μm
- Output: RAW10
- Lens Standards: C, CS (C-CS adapter included)
- IR filter
- Cord length: 200mm
- Tripod mount: 1/4” - 20
Kit includes
- Raspberry Pi camera with global shutter
- 200mm FPC cable
- Dust cover
- Focus adjustment
1183995
Data sheet
- Resolution
- 1,5 MPx
- Interface
- MIPI CSI-2
- Sensor
- IMX296
- IR filter
- Yes
- Lens assembly
- C/CS mount
Manufacturer BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
Responsible person BTC Korporacja sp. z o. o. Lwowska 5 05-120 Legionowo Poland sprzedaz@kamami.pl 22 767 36 20
