Raspberry Pi Camera Module 3 Wide NoIR
search
  • Raspberry Pi Camera Module 3 Wide NoIR
  • Raspberry Pi Camera Module 3 Wide NoIR
ID: 1183088
5056561800899
zł179.90
Tax included

zł146.26 tax excl.

The official camera module designed to work with Raspberry Pi minicomputers. Equipped with a Sony IMX708 sensor with a resolution of 12 Mpx and a lens with a viewing angle of 75 ° with autofocus. Version without IR filter. Raspberry Pi SC0875

24h
Available
Available quantity: 3
Raspberry Pi Camera Module 3, version:
Basic Wide NoIR
Wide NoIR
Kamami is the Approved Reseller of Raspberry Pi minicomputers and dedicated accessories.

Description

The Raspberry Pi Camera Module 3 NoIR camera module, equipped with a Sony IMX708 matrix with a resolution of 12 Mpx and a lens with a viewing angle of 120 degrees with autofocus controlled via the I2C interface. Due to the lack of an IR filter, the camera is adapted to work at night and is sensitive to infrared light. Compared to the previous module, sensitivity in difficult lighting conditions has been improved and hardware HDR support has been added. The PDAF (Phase detection auto focus) technology is responsible for smooth focusing. The camera is compatible with all Raspberry Pi models except the Raspberry Pi 400, however a special adapter will be required to connect to the Zero series. The module is supported by the Picamera2 Python library.

Kamami is an official distributor of Raspberry Pi minicomputers and dedicated accessories

Features

  • Works with all Raspberry Pi computers except the 400 (Zero, Zero W and Zero 2W models require a special adapter)
  • Sony IMX708 sensor with a diagonal of 7.4 mm
  • Resolution 11.9 Mpx
  • Autofocus controlled by I2C
  • PDAF (Phase detection auto focus) - provides smooth focus adjustment
  • Built-in lens with a viewing angle of 120°
  • No IR filter
  • High signal-to-noise ratio (SNR)
  • DPC (Defect Pixel Correction) function
  • Hardware HDR support (max. 3 Mpx)
  • Pixel size: 1.4μm × 1.4μm
  • Maximum photo size: 4608 x 2592 px
  • Supported video formats: 1080p50, 720p100, 480p120
  • Output format: RAW10
  • Improved sensitivity in difficult lighting conditions
  • Compatibility with Picamera2 library
  • 15x1mm FPC connector
  • Dimensions: 25x24x12.4mm

Kit Includes

  • Camera module
  • FFC tape
1183088

Data sheet

Resolution
11,9 Mpx
Interface
MIPI CSI-2
Sensor
IMX708
IR filter
No
Lens assembly
none
